Product descriptions from the supplier

Product Description

Strong Structure

Long Lifetime Filter Belt

Fully Auto Remote Control

No matter the filtration is for de-watering, concentrated metallurgical ore for a fine particle size or tailings slurry for dry stacking, the filtration facility is an essential process step.

High quality filtration and liquid-solid separation are keys to the popular Horizontal Vacuum Belt Filter. That is why it is widely used in many industries. The Vacuum Belt Filter is a relatively simple, yet highly effective.It is a new technology filter machine. It has a better function for sludge dewatering filtration process. And the sludge can be easily dropped down from the belt filter press because of the special material of filter belt. According to different materials, the belt filter machine can be configured with different specifications of filter belts to achieve high filtration accuracy. As a professional belt filter press manufacturer, Shanghai Junyi Filter Equipment Co.,Ltd will provide the customers with the most suitable solutions and best belt filter press price according to customers’ material.

Working Principle of Horizontal Vacuum Belt Filter Press

The Vacuum Belt Filter Press uses a screen cloth and rubber vacuum carrier belt in combination. As the fishtail feeder deposits slurry onto the surface of the filter cloth, the belt moves in a horizontal linear direction under the dam roller to form a cake of varying thickness. As the belt travels, negative vacuum pressure draws free filtrate out of the
slurry, through the cloth, along the grooves in the carrier belt and through the center of the carrier belt into the vacuum box. This process continues until the slurry has formed a solid filter-cake, which is then discharge at the head pulley end of the belt filter.

Features of Vacuum Belt Filter Press

* Higher Filtration rates with minimum moisture content.
* Lower operating and maintenance costs due to efficient & sturdy design.
* Low friction advanced air box mother belt support system, Variants can be offered with

slide rails or roller decks support system.
* Controlled belt aligning systems results in maintenance free running for a long time.
* Multi stage washing.
* Longer life of mother belt due to less friction of air box support.
* Drier filter cake output.
